RSMP v1

Binary format contract

This document is normative for the RSMP v1 archive format. RSMP stores result sample measurements together with the circuit identity needed to recover detectors and observables. v1 is a circuit-bound archive format, not a standalone detector-error-model sample format.

Circuit-Derived Lossless Transform

The v1 transform is lossless because it is derived from the original circuit, the circuit's noiseless reference sample, and the exact detector/observable linear relations over measurement bits. For each shot, the encoder maps the measurement vector into selected-detector bits plus free-measurement bits. The selected-detector part has rank equal to the detector matrix rank; the free-measurement part carries the remaining independent measurement columns.

Given the same original circuit, the decoder rebuilds the same transform, checks the circuit SHA-256 identity, recombines selected-detector and free-measurement coordinates, and applies the noiseless reference to reconstruct the original measurement bits. That map is invertible for the circuit and shape recorded in the header: no measurement bit is dropped, and detector and observable outputs are recomputed from the reconstructed measurements.

Binary Fields and Canonical Encoding

All fixed-width integers are unsigned little-endian. Bit-packed result streams use LSB-first bit order within each byte. Sparse syndrome payload counts and index deltas use canonical ULEB128: overlong encodings are malformed. Unused padding bits in dense final bytes must be zero padding.

The global header is exactly 152 bytes. header_len is 152 in v1.0 and must be checked before the value is trusted. It must be between 152 and 65,535.

The block header is exactly 108 bytes.

The archive trailer is exactly 64 bytes.

The magic values are RSTMSMP\0, RSMPBLK\0, and RSMPEND\0. v1 readers accept only major 1, minor 0. A nonzero required_flags value is RSMP_UNSUPPORTED_FEATURE; v1.0 has no defined optional flags, so a nonzero optional_flags value is malformed. All reserved fields and reserved flags must be zero. The global identifiers must be respectively 1 for canonical circuit text, SHA-256 canonical-circuit fingerprint, selected-detector/free- measurement transform, noiseless reference, and Zstandard frame codec suite.

shot_count is nonzero, and first_shot + shot_count must not overflow. The only syndrome stream codecs are empty (0), dense (1), and sparse LEB128 (2). The only free stream codecs are empty (0) and dense (3). A zero-length stream is canonical only as codec 0 with both declared lengths zero. Nonempty stream length sums must use checked arithmetic.

An archive for zero shots is exactly a global header followed by a trailer, with both trailer counts zero and no block magic between them. Empty-dimension streams in nonempty blocks use the canonical empty-stream representation above.

header_sha256 covers global-header bytes [0, 120). The block logical digest covers canonical uncompressed dense selected-detector bytes followed by dense free-measurement bytes. archive_sha256 covers the complete global header, all complete block bytes, and the trailer prefix [0, 32).

Support Boundaries

The original circuit is required for unpack and verify-only validation. The archive stores a circuit identity digest and shape, but it does not store the circuit text or a DEM that can replace the circuit. DEM-only input is unsupported for pack, unpack, and verify-only.

Sweep-bit circuits are unsupported in v1 and must fail with RSMP_UNSUPPORTED_SWEEP before archive bytes are produced or trusted.

RSMP v1 has sequential access only and no random shot access. A reader consumes blocks in order, validates the trailer at end of stream, and exposes no index that can seek directly to an arbitrary shot.

Integrity, Authentication, and Access Model

RSMP v1 checks archive integrity but archives are not authenticated. The header_sha256, per-block logical_payload_sha256, Zstandard frame checksums, and final archive_sha256 detect accidental or adversarial byte changes within their hash coverage, including the logical payload reconstructed from selected detector and free measurement streams. They do not prove who produced an archive, bind an external identity, or replace a signature/MAC layer.

A reader may return already-verified earlier blocks before a late trailer or trailing-data failure is discovered. Callers that need whole-archive acceptance must read through end of stream and finish the reader.

Resource Limits and Validation Precedence

Resource limits are checked before allocations or decompression work that would exceed those limits. The v1 defaults bound total shots, block shots, archive bytes, stream lengths, transform dimensions, and logical block working sets. Limit failures use RSMP_LIMIT_EXCEEDED.

Validation precedence is stable at the public error-code level. Readers check fixed record shape, magic/version/feature support, reserved fields, canonical integer and padding rules, circuit identity, shape agreement, declared lengths, decompression, logical digest, archive digest, trailer consistency, and trailing data in that order when the corresponding bytes are available. I/O failures are reported as RSMP_IO.

Stable Error Taxonomy

The public codes are:

• RSMP_BAD_MAGIC
• RSMP_UNSUPPORTED_VERSION
• RSMP_UNSUPPORTED_FEATURE
• RSMP_UNSUPPORTED_SWEEP
• RSMP_CIRCUIT_MISMATCH
• RSMP_SHAPE_MISMATCH
• RSMP_LIMIT_EXCEEDED
• RSMP_TRUNCATED
• RSMP_MALFORMED_ARCHIVE
• RSMP_DECOMPRESSION_FAILED
• RSMP_CHECKSUM_MISMATCH
• RSMP_LOGICAL_DIGEST_MISMATCH
• RSMP_TRAILING_DATA
• RSMP_IO

Structural parsing maps a bad magic to RSMP_BAD_MAGIC, a non-v1.0 version to RSMP_UNSUPPORTED_VERSION, unknown required features or unknown global v1 identifiers to RSMP_UNSUPPORTED_FEATURE, unsupported sweep circuits to RSMP_UNSUPPORTED_SWEEP, a mismatched circuit digest to RSMP_CIRCUIT_MISMATCH, shape disagreement to RSMP_SHAPE_MISMATCH, short records or streams to RSMP_TRUNCATED, reserved fields, canonical stream encodings, header lengths, parsed shot ranges, block ordering, padding, or declared-length arithmetic to RSMP_MALFORMED_ARCHIVE, Zstandard failures to RSMP_DECOMPRESSION_FAILED, archive/header checksum failures to RSMP_CHECKSUM_MISMATCH, logical payload digest failures to RSMP_LOGICAL_DIGEST_MISMATCH, bytes after a valid trailer to RSMP_TRAILING_DATA, and filesystem/stdin/stdout failures to RSMP_IO.

Compatibility Fixture Policy

The immutable v1 reader fixture is rstim/tests/fixtures/rsmp/v1/compat-v1.rsmp, described by rstim/tests/fixtures/rsmp/v1/manifest.toml and cataloged as compat_v1_two_block_sparse_dense. It contains one fixture, two blocks, and the syndrome codecs sparse and dense.

The policy is immutable/additive. Existing compatibility fixture bytes, manifest hashes, and catalog identity fields are not rewritten after publication. Future compatibility coverage must add new fixtures or new manifest entries instead of mutating this specimen.

Compression Evidence and Claim Limits

Committed compression evidence lives under benchmarks/rstim_vs_stim_simulator/results/rsmp-v1/. The checked gate names are benchmark_raw_lt_20pct, benchmark_zstd_lt_75pct, and high_entropy_raw_le_102pct; their arithmetic is integer cross-multiplication over recorded byte counts.

The evidence checker is:

python3 tools/check_rsmp_v1_compression_evidence.py \
  --results-dir benchmarks/rstim_vs_stim_simulator/results/rsmp-v1

The reproduction command for regenerating the evidence remains separate from readiness:

python3 -m benchmarks.rstim_vs_stim_simulator.run_rsmp_compression \
  --rstim target/release/rstim \
  --catalog rstim/tests/fixtures/rsmp/catalog.json \
  --case stim_surface_d11_r100 \
  --shots 1024 \
  --seed 7 \
  --zstd-level 3 \
  --out-dir /tmp/rstim-rsmp-v1-evidence

The benchmark row also carries Stim-format baselines for exactly b8, r8, and ptb64. All three serialize the same canonical 1024-shot, seed-7 measurement batch; r8 is produced with the pinned stim convert command and ptb64 with the pinned stim Python API (the Stim CLI streams single records and cannot write ptb64). Each baseline records its raw byte count, its direct level-3 Zstandard byte count under the same recorded contract, the conversion argv, the artifact SHA-256, and a round-trip b8 SHA-256 that must equal the canonical measurement SHA-256. The summary and report state byte counts and ratios relative to the RSMP archive only; no universal cross-format compression superiority is claimed. The pinned Stim binary identity, version, and every conversion command are recorded in environment.json.

The runner writes the bundle to a temporary output directory so the evidence check above stays separate from regeneration. To publish a regenerated bundle over the committed location, copy the five generated files:

cp /tmp/rstim-rsmp-v1-evidence/{raw.jsonl,summary.json,report.md,environment.json,artifact-sha256.json} \
  benchmarks/rstim_vs_stim_simulator/results/rsmp-v1/

Regeneration must run from a clean Git tree so the recorded environment has git.dirty=false.

The recorded environment includes producer identity, Git state, Rust target, Cargo.lock hash, zstd crate versions, native zstd version, full command argv, and artifact SHA-256 values. These gates prove only the pinned rsmp v1 evidence cases under that recorded producer and zstd contract. No fixed wall-clock performance gate, cross-version byte-for-byte writer determinism, or broader compression claim is made. No fixed wall-clock performance gate is part of readiness.

Known Byte Vectors

GLOBAL_VECTOR = [
52 53 54 4d 53 4d 50 00 01 00 00 00 98 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 01 00 01 00
01 00 01 00 01 00 00 00 00 10 00 00 00 00 00 00
02 01 00 00 00 00 00 00 01 02 00 00 00 00 00 00
02 00 00 00 00 00 00 00 01 01 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 01 02 03 04 05 06 07
08 09 0a 0b 0c 0d 0e 0f 10 11 12 13 14 15 16 17
18 19 1a 1b 1c 1d 1e 1f a0 a1 a2 a3 a4 a5 a6 a7
a8 a9 aa ab ac ad ae af b0 b1 b2 b3 b4 b5 b6 b7
b8 b9 ba bb bc bd be bf
]

BLOCK_VECTOR = [
52 53 4d 50 42 4c 4b 00 01 00 00 00 08 07 06 05
04 03 02 01 18 17 16 15 14 13 12 11 21 00 00 00
00 00 00 00 01 00 03 00 00 00 00 00 05 00 00 00
00 00 00 00 0d 00 00 00 00 00 00 00 02 00 00 00
00 00 00 00 09 00 00 00 00 00 00 00 c0 c1 c2 c3
c4 c5 c6 c7 c8 c9 ca cb cc cd ce cf d0 d1 d2 d3
d4 d5 d6 d7 d8 d9 da db dc dd de df
]

TRAILER_VECTOR = [
52 53 4d 50 45 4e 44 00 01 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
80 81 82 83 84 85 86 87 88 89 8a 8b 8c 8d 8e 8f
90 91 92 93 94 95 96 97 98 99 9a 9b 9c 9d 9e 9f
]
